MagicWave (5) Process button ... for selecting the process, depending upon which operating
control panel
(continued)
(6) Adjusting dial ... for altering parameters. If the indicator is lit up on the adjusting
(7) and (8) Parameter selection buttons ... for selecting the parameters
It is also possible to change parameters by means of the parameter selection buttons (7)
and (8) while the welding operation is in progress.
"Min." and "max." are used for setting ranges that differ according to power source .
Available parameters where 2-step (2) and 4-step (3) mode have been selected:
unit
setting range
factory setting
Important! The starting current I
DC- welding" operating modes.
unit
MW 1700
MW 2200
MW 4000
MW 5000
Important! On welding torches with Up/Down functionality, the entire setting range can
be selected while the machine is idling. During welding, the main current can be cor-
rected in steps of +/-20 A.
mode has been selected
If 2-step / 4-step mode has been selected:
TIG-DC- welding
TIG-AC welding
TIG-AC welding with activated cap-shaping function
If "Rod electrode (MMA) welding mode" (5) has been selected:
Rod electrode DC+ welding
Rod electrode DC- welding
Rod electrode AC welding
dial, then the selected parameter can be altered.
Starting current I
S
%
0 - 200 % of main current I
35 AC
50 DC
Main current I
1
A
3 - 170
3 - 220
3 - 400
3 -500
1
is saved separately for the "TIG-AC welding" and "TIG
S
10
