Aquatec® Ocean VIP Ergo / Aquatec® Ocean Dual VIP Ergo
1. Push down all four foot pedals for the castors to lock
them.
2. Hold the shower chair at its push bar B.
3. Pull and hold the activation handle A.
The activation handle is equipped with a locking
device. For activating the handle, the locking device
has to be pulled in advance.
4. Tilt the backrest to the required position.
5. Release the activation handle to fix the backrest in the
current position.
26
Increased force is needed for tilting backwards
without seated user. Automatic tilting upwards
without seated user when activation handle is pulled.

6.6 Engaging/Disengaging the Castor Locks

CAUTION!
Risk of Trapping/Squeezing
All castor locks are foot-operated.
– Do not operate the castor locks by hand.
1. To lock the castor locks step on the rear end of the
pedal A until it engages.
The castor is now locked in position and cannot
swivel any longer.
2. To unlock the castor locks step on the front end of the
pedal until it disengages.
Castor with blue pedal (option) is used to engage
only the swivel lock for easier straight movement.
