BLADE SHARPENING ( fig. 13) :
n
10 hours working. To obtain a perfect sharpening you need to use and electric sharpening machine ( 15.000/20.000 turns/minute>) , grinding-headed
with a diameter 25 mm and lenght 35 mm. The blade has to be sharpened from the internal part of the rod to tip.end section using the head grinding.
The blade sections have to be sharpened in a 25° deg. angle.
DESCRIPTION : ( fig. 14)
n
(5) scything bar (6) driving lever for reverse .

TECHNICAL DATA :

n Gauge : 340 mm. - bar width : 870 mm - total motormower lenght : 14000 mm - total motormower height : 950 mm .
Pneus : 2 tyres 4.00-6 - mass kgs. 65 . For further technical data and details on engine , please see the enclosed instructions manuals .
AIR NOISE AND VIBRATIONS :
n
Handlebars vibrations according to EN 1033. Noticed value = 8,18 m/s

ACCESSORIES

n The machine can be transformed with the application of 4 very useful accessories : adjustable front brush cm. 105 , front
rotavator with fixed cover cm. 50 , grassland mower cm. 53 and front snow-blade cm. 85 . The brush can be used for the cleaning of the external yards.
The rotavator can be used for the scraping and cleaning of the ground from the weed . The grassland mower can be used for the recurring scythe of
the meadows. The blade can be used to shovel the snow away.
The brush , the rotavator and the grassland mower are to be fixed in place of the scything bar, inserting the pin into the seat of the accessories
attachment and the belt on the bigger pulley. The snow blade can be fixed with the pin into the seat of the accessories attachment then it has to be
tightened with a "R" pin.
according to the frequency and the type of use , the cutting sections have to be sharpened about every
1) throttle control handle (2) transmission control for driving wheels lever (3) bar connection driving lever (4) engine
Acoustical pressure value on the working place according to document EN 12733 LA eq = 83,5 Db (A).
.
