Operating and Maintenance Instruction FCU 8000-1 series

7.1.2 "Measuring and switching" mode

Description:
Mode M2 "Measurement and switching" can be used to control limit switch relays for
signalling whilst simultaneously measuring the cleanliness of the oil in the hydraulic
system. This means that, in this menu, the user can switch external devices for warning
(alarm) by means of two relays. This could for example be a warning light at an
observation point.
Parameters for triggering these switching processes can be:
· The flow rate
· The cleanliness of the hydraulic fluid (given according to NAS or ISO standard)

Typical application

Signal switching to a control panel (observation point) on fully-automatic test rigs.
Operation:
The function "Measure + switch" is selected from the "Mode" menu
MODE-key
M1: Measure
M2: Measure+switch
M3: Filter to
M4: Filter from to
M5: Rinse BS
M6: Bottle sampler
The switching limits are input in the "Limits" menu.
LIMITS-key
M2: Relay 1
M2: Relay 2
M3: Filter to
M4: Filter from to
M5: Rinse BS
M6: Bottle sampler
HYDAC Filtertechnik GmbH
Doc.: 3109776 Ed.: 01/13.02.2002
ok
start
E
Page 93
