Operating and Maintenance Instruction FCU 8000-1 series

5.5.2 Rear view

Figure 4 : Rear view
HYDAC Filtertechnik GmbH
Doc.: 3109776 Ed.: 01/13.02.2002
Caution !
Do not
lock
OUTLET INLET
Max. 3bar Max. 350bar
43 PSI 5000 PSI
Filter Element
0060 D 005 BN/HC
E
outlet (return line to tank)
inlet (inlet for hydraulic fluid)
filter cover
on/off switch
24 V DC connection for mains/
charging unit
POWER INPUT
O / I
24 V= / 1 A
serial interface
control port
PC CONTROL
case earth connector
Page 79
