7.3 Working with the "MEMORY" functions

The FCU can store up to 100 logs with up to 3000 log lines.
Within the "MEMORY" menu the actual used space in % and the number of stored logs is
shown in the first line of the display.
Before starting a measurement, check that there is sufficient memory for
the expected duration of the measurement.
If during an active measurement no more free space is available, the oldest log is deleted.
If only one log is stored in the memory (the active measurement) the oldest
measurements will be overwritten.
Logs are easy to identify by the measurement point designation stored in the log heading.

7.3.1 Inputting the measurement point designation

Description
The alphanumeric measurement point designation can be entered in this sub-menu point
and stored.
MEMORY key
Measurement point
Averaging interval
Selective deletion
Delete all
Change meas. point
Operation
memory
The following symbols can be selected using the
for the measurement point designation.
HYDAC Filtertechnik GmbH
MEMORY
Meas. point
ok
start
ok Meas. point :
start
ABC123
Select symbol
+
E
Doc.: 3109776 Ed.: 01/13.02.2002
7 8 9
4 5 6
1 2 3
0
or
+
Select the position
-
in meas. point designation
and keys &/or the number keys
-
ok
start
Page 103
