Operating and Maintenance Instruction FCU 8000-1 series
5.5.5.3 Programmable relay limit switches
FCU 8110 :
M2 switching limits
2 µm channel NAS
5 µm channel NAS
15 µm channel NAS
25 µm channel NAS
50 µm channel NAS
100 µm channel NAS 1
2 µm channel ISO
5 µm channel ISO
15 µm channel ISO
Flow rate
M3 filtration limit
ISO
NAS
M4 filtration limits
ISO
NAS
Test cycle time
FCU 8210 :
M2 switching limits
4 µm channel ISO
(c)
6 µm channel ISO
(c)
14 µm channel ISO 5
(c)
Flow rate
M3 filtration limit
ISO
M4 filtration limits
ISO
Test cycle time
HYDAC Filtertechnik GmbH
min
1
1
1
1
1
10
7
5
0
10 / 7 / 5
1 / 1 / 1
10 / 7 / 5
1 / 1 / 1
0
min
10
7
0
10 / 7 / 5
10 / 7 / 5
0
E
Doc.: 3109776 Ed.: 01/13.02.2002
Max
15
15
15
15
15
15
25
23
21
150
25 / 23 / 21
15 / 15 / 15
25 / 23 / 21
15 / 15 / 15
1440
Max
25
23
21
150
25 / 23 / 21
25 / 23 / 21
1440
Page 86
