Operating and Maintenance Instruction FCU 8000-1 series

16 Technical details

Continuous measured value display via LCD
Self diagnosis:
Calibration
Re-calibration
Measuring range
Display range
Data memory with battery back-up:
Input operating pressure:
Ports: Rear:
Return line (Outlet) flow rate:
Measurement flow rate:
Permissible viscosity range:
Temperature range of fluid:
Voltage supply:
Power consumption:
Battery life:
Integral printer:
Serial interface:
Ambient temperature range:
HYDAC Filtertechnik GmbH
Doc.: 3109776 Ed.: 01/13.02.2002
continual automonitoring
with error display in the LCD
FCU 8110 : ISO 4402 / NAS 1638
FCU 8210 : ISO 11171
recommended : annual
ISO 0/0/0...23/21/18
NAS 0 ... 12
ISO 0/0/0...25/23/21
NAS 0 ... 15
Can record up to 3000 measured values.
Pressure port Inlet: 1 - 350 bar
Return line Outlet: max. 3 bar back pressure
Inlet: Minimess coupling system 1620
Outlet: DN 7 plug
approx. 800 ml/min at 350 bar
20 - 80 ml/min
5 ... 800 mm 2 / s
0 ... +70° Celsius
24 V DC, ± 25%
25 Watt max.
approx. 3 hours (online printing switched off)
Matrix printer
RS 232 (on /-BUS models: RS 485)
with 15 pole Sub-D plug
5 ... +50° Celsius
E
