CONNECTING THE REFRIGERATOR
1
TO THE HOUSE WATER LINE
(icemaker and dispenser models)
A cold water supply is required for automatic
icemaker and dispenser operation. If there
is not a cold water supply, you will need to
provide one. See
section.
NOTES:
• Before making the connection to
the refrigerator, be sure the refrigerator
power cord is not plugged into the wall outlet.
• If your refrigerator does not have a water
water supply has sand or particles that
could clog the screen of the refrigerator's
water valve. Install it in the water line near
the refrigerator. If using GE SmartConnect
Refrigerator Tubing Kit, you will need an
additional tube (WX08X10002) to connect
A If you are using copper tubing, place a
compression nut and ferrule (sleeve) onto
the end of the tubing coming from the house
cold water supply.
If you are using the GE SmartConnect
tubing, the nuts are already assembled
to the tubing.
B If you are using copper tubing, insert
the end of the tubing into the refrigerator
connection, at the back of the refrigerator,
as far as possible. While holding the tubing,
If you are using GE SmartConnect
insert the molded end of the tubing into
the refrigerator connection, at the back of
the refrigerator, and tighten the compression
nut until it is hand tight. Then tighten one
additional turn with a wrench. Overtightening
may cause leaks.
Installation Instructions
™
™
tubing,
™
30
C Fasten the tubing into the clamp provided to
hold it in position. You may need to pry open
the clamp.
Tubing Clamp
Compression Nut
Ferrule
(sleeve)
Refrigerator
Connection
TURN ON THE WATER SUPPLY
2
water supply) and check for any leaks.
PLUG IN THE REFRIGERATOR
3
Before plugging in the refrigerator, make sure
the icemaker power switch is set to the O
position.See the grounding information
attached to the power cord.
SmartConnect Tubing
™
Option 2
