6
Technical data
Rated voltage
Cutting width
Cut height
Height adjustment of guide bar
Height adjustment
Collection bag volume
Weight (without battery)
Blade information:
Manufacturer:
Blade code:
Subject to technical changes!
Noise and vibration
WARNING
Noise can have serious effects on your health. If the
machine noise exceeds 85 dB, please wear suitable
hearing protection for you and persons in the vicinity.
The noise and vibration values have been determined
through a standardised measurement process.
Noise data
Sound pressure L
pA
Measurement uncertainty K
Sound power L
wA
Measurement uncertainty K
Vibration parameters (hand/arm vibration)
Vibration a
h
Measurement uncertainty K
The total vibration emission values specified and the de-
vice emissions values specified have been measured in
accordance with a standardised test procedure and can
be used for comparison of one electric tool with another.
The total noise emission values specified and the total vi-
bration emission values specified can also be used for an
initial estimation of the load.
WARNING
The noise emission values and vibration
emission value can vary from the specified
values during the actual use of the power
tool, depending on the type and the manner
in which the electric tool is used, and in par-
ticular the type of workpiece being pro-
cessed.
Try to keep the stress as low as possible. For example:
Limit working time. In doing so, all parts of the operating
cycle must be taken into account (such as times in
which the power tool is switched off or times in which it
is switched on, but is not running under a load).
26 | GB
40 V (2 x 20 V)
430 millimeters
6-level adjustment
3-level
25 - 75 mm
50 L
16.2 kg
Royal Garden
RG8A109
78.5 dB
3.0 dB
pA
90 dB
2.08 dB
wA
< 2.5 m/s
1.5 m/s
www.scheppach.com
7
Unpacking
WARNING
The product and the packaging material are not
children's toys!
Do not let children play with plastic bags, films or
small parts! There is a danger of choking or suffo-
cating!
• Open the packaging and carefully remove the product.
• Remove the packaging material, as well as the pack-
aging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the product and accessory parts for transport
damage. Immediately report any damage to the trans-
port company that delivered the Product. Later claims
will not be recognised.
• If possible, keep the packaging until the expiry of the
warranty period.
• Familiarise yourself with the product by means of the
operating manual before using for the first time.
• With accessories as well as wearing parts and re-
placement parts use only original parts. Spare parts
can be obtained from your specialist dealer.
• When ordering please provide our article number as
well as type and year of manufacture for the product.
8
Assembly
CAUTION
Danger of injury!
Do not insert the battery until the battery-powered tool
is ready for use.
2
2
CAUTION
Danger of injury due to rotating blade. Only work on the
product when the blade is switched off and stationary!
ATTENTION
Always make sure the product is fully assembled
before commissioning!
ATTENTION
Ensure that the cable is not squeezed during assembly.
8.1
Installation of the lower push bar
(4) (Fig. 1, 3, 4)
Note:
Make sure that the teeth mesh.
1. Attach the lower push bar (4) to the pre-fitted screws.
2. Screw down the lower push bar (4) with one washer
(4a) and one quick-clamp lever (4b) on each side. En-
sure that the cable (10), which will later be attached
with a cable clip (9), is not in the way.
3. Lock the two quick-clamp levers (4b) by pressing
them in the direction of the lower push bar (4).
They must rest against the lower push bar (4) in such
a way that they can be tightened with moderate force.
