• Permitted cutting disc designs:
segmented diamond discs with maximum slots be-
tween the segments of 10 mm, only with negative cut-
ting angle.
Disc diameter: 125 mm
disc thickness: 1.9 mm
8.1
Fitting/dismantling the cutting disc
(6) (Fig. 1, 3)
ATTENTION
Risk of damage!
Only operate the spindle lock when the spindle is sta-
tionary. The power tool may otherwise be damaged.
WARNING
Always make sure that the tool attachment is fitted cor-
rectly!
Notes:
Only exchange separators in pairs!
Do not use separate reducing bushes or adapters to
make cutting discs with a large hole fit.
At least one spacer disc must be fitted between two sepa-
rating discs.
1. Press the spindle lock (13) to fix the mounting spindle
(7).
Continue to press the spindle lock (13).
2. Remove the flange nut (8). Use the enclosed flange
spanner (A).
You can release the spindle lock (13).
3. Remove the separating discs (6) and the spacer discs
(B/C).
The mounting flange (14) remains on the mounting
spindle (7).
If you have removed the mounting flange (14), ensure
that it is positioned correctly. The contour of the
mounting flange (14) must point in the direction of the
motor. When you turn the mounting flange (14), the
mounting spindle (7) must also turn.
4. Guide the cutting disc (6) from below through the pro-
tective cover (3) and place it on the mounting spindle
(7).Ensure the correct direction of rotation of the cutting
disc!The direction of rotation is indicated by arrows on
the cutting disc (6) and the protective cover (3).
5. Set the desired cutting width by selecting the spacer
discs (B/C).
Slide it onto the mounting spindle (7).
6. Screw the flange nut (8) onto the mounting spindle (7)
and fix the separating discs (6) and the spacer disc
(B/C).
7. Press the spindle lock (13) to fix the mounting spindle
(7).
Continue to press the spindle lock (13).
8. Tighten the flange nut (8). Use the enclosed flange
spanner (A).
24 | GB
8.1.1
WARNING
Regardless of the desired groove width, all
spacer discs supplied must always be fitted.
Otherwise the cutting disc may come loose
during operation and cause injury.
The groove width results from the number of spacer discs
(B/C) between the cutting discs (6) and the cutting width
of the cutting discs (6).
The groove width is calculated as follows:
Groove width = thickness of the spacer discs (B/C) +
width of the separating discs (6).
Thickness of the spacer discs:
Spacer discs (B)
Spacer discs (C)
Thickness of the cutting discs:
Cutting disc (6)
Please consider the permissible groove width mentioned
in the technical data (see chapter 7).
Always use the flange nut (8) and the mounting flange
(14).
You may use the product with a maximum of four cutting
discs (6).
8.2
Setting the cutting depth (Fig. 4)
1. Loosen the locking lever (2).
2. Set the cutting depth scale (12) on the protective cov-
er (3) to the desired depth.
3. Retighten the locking lever (2) of the cutting depth
scale (12).
8.3
Dust extraction
The product generates a considerable amount of dust
during operation.
Therefore, wear a dust mask and always connect an ex-
traction system* to reduce dust exposure.
If the dust extraction system malfunctions, stop working
and rectify the fault!
* = may not be included in the scope of delivery!
8.3.1
Notes:
Motor damage caused by a lack of suction is not covered
by the warranty.
The extraction system must be approved for the ex-
traction of stone dust.
1. Connect the hose of a suitable extraction system*
(e.g. industrial hoover) directly to the extraction nozzle
(9).
* = not included in the scope of delivery!
www.scheppach.com
Adjusting the groove width
(Fig. 1, 3, 10)
Mounting the dust extraction system
(Fig. 5)
4.70 mm
6.70 mm
1.90 mm
