MIDI
Preset MIDI Out settings
ON PRESET LOAD
MESSAGE
A
B
E
F
TYPE
None
•
ON PRESET LOAD MESSAGE: Set up to 12 MIDI commands
that will be sent once you load the current Preset.
•
A-H FOOTSWITCHES: Tapping them will allow you to modify
the type (CC/CC Toggle/PC), channel, command number, and
value (0 - 127) of the message assigned to each footswitch.
•
EXP PEDAL 1-2: Can switch between unassigned (none) and
CC in the type field. Once it's assigned, you can modify the
channel, command number, min value, and max value.
•
TYPE: When available, you can select the type of message that
will be sent (CC/CC Toggle/PC). For expression pedals, only CC
messages are available.
CC TYPE
•
CHANNEL: Choose from 1 to 16 to select the channel that will
send the MIDI commands.
•
CC#: Choose from 0 to 127 to select the CC number.
•
VALUE: Choose from 0 to 127 to select the value that will be
sent.
CC TOGGLE TYPE
•
CHANNEL: Choose from 1 to 16 to select the channel that will
send the MIDI commands.
•
CC#: Choose from 0 to 127 to select the CC number.
•
MIN VALUE: 0 - 127. Determines the value sent when the
footswitch LED is dim.
•
MAX VALUE: 0 - 127. Determines the value sent when the
footswitch LED is bright.
C
D
G
H
Clear all
Done
EXP 1
EXP 2
92
