Setup Examples
Seven Cable Method (7cm)
With the seven cable method, you can set two separate rows to
use the effects included on the Quad Cortex with two external
amplifiers.
1. Connect your instrument to Input 1.
2. Add all the pre effects blocks you want on the first row of The
Grid.
3. Use an A/B splitter to route the signal to the second row.
4. Add an FX Loop block on Rows 1 and 2. The one on the first
row must be set to Send 1 | Return 1, and the second one to
Send 2 | Return 2.
5. Add post effects after the FX blocks. Set the outputs of each
row to Output 3 and 4 respectively.
6. Connect a cable from Send 1 of the Quad Cortex to the
instrument input on the first amp. Connect another cable from
Send 2 of the Quad Cortex to the instrument input on the
second amp.
7. Connect the Effects Loop Sends from each amp to Return 1
and 2 on the Quad Cortex.
8. Finally, connect Outputs 3 and 4 of the Quad Cortex to the
Effects Loop Return of each amp.
67
