Setting up your Quad Cortex
•
LIMITER [dB]: Gain reduction meter. Allows you to bring up the level
without allowing the peaks to clip the output.
•
MUTE SWITCH [dB]: Tap to ativate/deactivate the Output(s).
OUT3/OUT4: TRS outputs that allow you to connect Quad Cortex to stereo
monitors, FRFR cabinets, PA systems, and more.
•
OUT LEVEL KNOB [dB]: Sets the output level.
•
OUT LEVEL [dB]: Output signal meter.
•
LIMITER [dB]: Gain reduction meter. Allows you to bring up the level
without allowing the peaks to clip the output.
•
MUTE SWITCH [dB]: Tap to ativate/deactivate the Output(s).
SEND1/SEND2: TRS outputs that allow you to connect Quad Cortex to
stereo monitors, FRFR cabinets, PA systems, pedals, and more. "TRS to TS"
cables are also supported to attenuate hum.
•
SEND LEVEL KNOB: Sets the output level.
•
OUT LEVEL [dB]: Output signal meter.
•
LIMITER [dB]: Gain reduction meter. Allows you to bring up the level without
allowing the peaks to clip the output.
HEADPHONES OUT: TRS output that allows you to connect Quad Cortex to
stereo headphones. All outputs that are being used on The Grid will display here
allowing you to customize your headphone mix.
•
HP LEVEL KNOB: Sets the output level.
•
OUT KNOBS: Sets the mix level of the selected output separately.
•
OUT METERS [dB]: Output signal meters.
CAPTURE OUT: Dedicated output for external devices (Neural Capture only).
Others
USB: Dedicated port for computer integration.
•
USB LEVEL KNOB: Sets the level of the audio transmission.
•
HP SELECT KNOB: The headphones feed when using Quad Cortex as a USB
audio interface. It can be set to "None", "USB 1/2", "USB 3/4", or "Both".
•
DRY-WET SWITCH: Swap between Clean DIs or processed signal fed into USB
Outputs 1-2 or 3-4 (Inputs 1-2 and 3-4 on your DAW).
MIDI IN: MIDI input.
MIDI OUT: MIDI output.
•
MIDI THRU SWITCH: Enables or disables the MIDI Thru
function.
18
