I. EQUIPMENT START-UP
Scrub the walls and bottom of the swimming pool and clean the skimmers.
1
If the water is not new, renew ¼ of the pool
Measure the TAC (Titre Alcalimétrique Complet: Full Alkali metric Title) with test strips or tablets
2
(this must not be less than 150 mg/L or 15°F). If necessary, slowly correct by gradually adding TAC
PLUS.
Measure the pH (with red-phenol for example)
3
The correct value is about 7.2
If necessary, correct the pH manually by directly adding the necessary quantity of pH+ or pH- into
4
the pool to bring the pH to the 7.2 value
5
Check the correct connection and installation of the COMBIPOOL² and the condition of the pump
body and the inlet and outlet tubes.
Start the device and proceed to the adjustments corresponding to your application (see H. Combipool
pH/Redox settings, page 32)
Notes:
6
The pH injection is automatic and proportional: after a few minutes, and when the pH of the pool
will be different from the set point, the pump will start itself and correction fluid will flow through
the transparent tubes, the injection will be performed in small cycles shorter as the closer we get
to the set point
Remanent injection is automatically according to redox measure
24 hours after the shock dose, backwash the filter to discharge all the impurities and miscellaneous
7
pollution to the drains
In the case of hard or very hard water (borehole water not recommended) add BIO-UV STOP
8
CALCAIRE at the beginning and middle of the season if necessary (degree of hardness > than 25°F or
25 PPM)
- Observe the following filtration times:
Water temperature
Filtration time (over 24h)
For heated swimming pools, we strongly advise you not to heat the water to a temperature of more than 28°C in
order to protect your coating, protect your liner and keep greater COMFORT.
Combipool-pHRedox_(Multi) - DOC015452 - Ind. A03 - 23/12/2020
Marque, Modèles et Brevets déposés - Produits exclusifs
Carry out a shock dose treatment with the filtration operating 24H/24 and a pH at 7.2
by pouring the dose of BIO-UV Choc corresponding to the volume of your pool
(2liter/10m3) in front of the discharge points.
20°C
10h
22°C
24°C
12h
14h
26°C
28°C
16h
24h
