E. COMBIPOOL PH/REDOX DESCRIPTION
1. External view
Digital
display
pH probe
connector
Redox probe
connector
2. Internal view
pH probe
connector
Redox
probe
connector
Combipool-pHRedox_(Multi) - DOC015452 - Ind. A03 - 23/12/2020
Marque, Modèles et Brevets déposés - Produits exclusifs
220V
plug
Automatic control
Setting
buttons
pH pump
Redox pump
On/off
switch
0,5A fuse
(Time
delay)
220V
supply
connector
Automatic
control
connector
