3. About the pH probe
The pH sensor must always be in the water, only install it when the pipes will be filled with water, make
sure to keep the little original bottle (bulb protection) for winter storage
•
Handle it with CARES
•
NO MASSIVE ADDITION of chemical upstream of it
•
Probe winterizing: disconnect the cabinet and remove the probe holder. Store it with bulb immersed in its
original bottle filled with fresh water in a tempered and dry place. Close the probe holder with a ½'' plug.
The pH electrode is composed of glass elements, so handle it with care.
All our electrodes are tested and calibrated with the Combipool pH/Redox on the manufacturing line before
packaging.
No pH electrode could be changed under warranty without prior manufacturer's permission. In this case, in
order to be accepted for review, the probe will necessarily be returned to us in its original bottle filled with
water.
4. Mounting of inlet and outlet tubes
Suction
strainer
The flexible PVC inlet tube is immersed with her
strainer in the can of product to inject and is
connected to the pump (in let on the left). Then
tighten the nut on the fitting.
Combipool-pHRedox_(Multi) - DOC015452 - Ind. A03 - 23/12/2020
Marque, Modèles et Brevets déposés - Produits exclusifs
Injection valve
The outlet tube is connected to the pump (outlet
on the right) on one end and to the piping on the
other end through the injection valve mounted on
a pipe saddle.
Copyright BIO-UV
Page 29
