Assembly
Condenser coolant supply
➜ Required tube: PTFE, transparent (included, sold by the meter).
➜ Position the external condenser and cut the pieces of tube required to the necessary
length (inlet, outlet).
➜ Connect the inlet and return tube to the condenser with connections [1] and [2]
and make the connections to the inlet and outlet of the external condenser. The
flow connection of the coolant can be set as required, i.e. the connections are
interchangeable.
