Assembly
Retaining clips for the base
To stabilize the overall system, the four rotary evaporator feet are fixed to the base
with clip-on retaining clips [1]:
➜
Remove the rotary evaporator front panel to install or remove the front two
retaining clips [2] (the rear clips are directly accessible).
➜
[3a]: Retaining clip attached; [3b]: Retaining clip in plugged position, front left.
➜
[4]: Retaining clip in plugged position, front right.
Before commissioning, make sure that all four clamps are properly
inserted to ensure the stability of the entire system!
72
