Assembly
Collector
The following figure shows the preassembled collector in the as-delivered condition:
1
2
3
4
5
6
Component / Function
Collector vessel
Retaining and stabilization element
Strain relief, condenser fitting
Intermediate valve V4
Collector sensor S2
Distillate valve V2
80
