Assembly
Tube connections
Make the required tube connections between the vacuum unit, the
buffer vessel, the collector and the educt sensor vessel as shown in
the following sections.
Only use the pieces of tube supplied as raw material for all tube
connections.
Always select the tube diameter to match the respective
connections.
Be sure to cut the tube pieces at both ends at right angles and flat,
using a suitable tool.
Each cut surface of the tube must be in contact with the counter-
part over the entire diameter.
This is to ensure that every connection closes sufficiently tightly!
Tubing set (included)
64
