Description of the items relating to the outputs:
Indicates the number of the output (relay). The configurable outputs ranging from 1-9.
OUTPUT N.
The output of 0 indicates that there is no output associated with that alarm level.
If the output boards are not properly connected or mounted, for safety, the
corresponding outputs cannot be configured.
If the board ES414 is not connected to the terminal OUT 1-4 outputs will only be
•
available from 5 to 9.
If the board ES414 is not connected to the terminal OUT 5-8 outputs will only be
•
available from 1 to 4 and 9.
If it was not connected any board ES414, the only output available is 9.
•
If output cards have not been installed into the Remote Units, the corresponding relay
•
will not be available. (for the 1
The outputs have to configure in a unique way. So, if you were choosing the same output for
different alarm levels will be considered valid, only the configuration of the higher alarm. You
cannot choose the same output for a level of alarm and fault
SILENCEABLE Indicates that the output is disabled, the Silence time, when RESET is performed.
This function can be used for the outputs connected to audible warning devices
SILENCE T.
Indicates the Silence time (adjustable from 0 to 300 seconds), so Silenceable output
is cancelled by RESET.
DELAY ON
is the relay delay (Adjustable from 0 to 300 seconds) associated with an alarm
threshold.
If the alarm type was selected as PARKING EN and you were programming the output on the
threshold 3, this delay can only be set from 60 to 300 seconds
The first item DELAY OFF (adjustable from 0 to 300 seconds), is the relay's delay, to
DELAY OFF
return to normal status, when it ends the alarm condition.
The second item, TIME ON (adjustable from 0 to 300 seconds) can only be used to
TIME ON
stop the alarm output after a preset time, even if the sensor remains above the alarm
threshold set. (It can be used to activate devices that cannot be powered on or to
send a pulse to a phone-dialer).
The two functions HISTER.OFF and TIME ON, cannot be used together, or with the SAVE
function. For safety, if the delay is set other than zero, the parameter stores will be
automatically changed to NO.
setting it to YES, indicates that the output operation is in POSITIVE LOGIC or the
POS.LOGIC
relay is normally activated, so, in case of failure automatically moves into the position
of the alarm, and then the NC contact becomes NO.
setting it to YES, indicates that the relay remains in alarm, even if the sensor back
LATCHED
below the alarm set. To bring it back into the normal, RESET must be performer.
The function LATCHED, cannot be used simultaneously with DELAY OFF or TIME ON. For
safety, if the parameter LATCHED, was set YES, the parameters DELAY OFF and TIME
ON, will be automatically set to Zero
At the end of the screen is written SAVE to save the configuration entered. Pressing
confirmation window will appear. Press again
changes.
Only for double sensors, TS255 series, at the end of the screen,
the message CONTINUE appears. Because in this case, must be
programmed two consecutive sensors. Only after the second
configuration, you can save the configuration entered.
If the set thresholds were in contrast with the criteria for this type of alarm
set, or if it had selected the same output for one of the alarm levels and
the Fault, a warning message will appear. --------------------------------------
Then the screen returns to the configuration of the sensor.
