IST-1424.CE02.02
Inputs (4÷20mA Gas Detectors) configuration - Remote Unit no.2 (CE380UR)
Sensor Number [17÷24]
Sensor Model
Type
(Flammable,
Toxic,
Refrigerant)
Gas Detected (Name or Formula)
Unit of measure
(% LEL, %vol, ppm, ppb or °C)
Full Scale
(Max 9.99 oppure 99.9 oppure 9999)
Alarm Type (Increasing, Decreasing,
Oxygen, TLV, Parking-EN)
Zone (1÷2)
T.W.A. (Only alarms PARKING-EN)
Threshold 1 (Alarm 1)
Output 1 (Relay Number)
Threshold 2 (Alarm 2)
Output 2 (Relay Number)
Threshold 3 (Alarm 3)
Output 3 (Relay Number)
Fault (Relay Number)
Outputs (relays) configuration of the Remote Unit no.2 (CE380UR)
Output Relay Number [18÷25]
(3)
Silenceable
(NO/YES)
Time of Silence (from 0 to 300 Seconds)
(4)
Hysteresis ON
(from 0 to 300
Seconds)
(5)
Hysteresis OFF
(from 0 to 300
Seconds)
(6)
Time ON
(from 0 to 300 Seconds)
Positiv Logic
(NO/YES)
(7)
Latched output
(NO/YES)
(1)
st
NOTA
Only if the 1
Expansion Board ES380UR with 4 relays is installed.
(2)
nd
NOTA
Only if the 2
Expansion Board ES380UR with 4 relays is installed, for a total of 4 (1
Relay Outputs.
(3)
NOTE
Normally leave NO. It is only used to temporarily disable the outputs related to audible warning devices.
(4)
NOTA
It is recommended to always set a value between 10 and 60 seconds. (typically 10 to 20 sec. for Optical/Acoustic
alarms and 30 to 60 sec. for Solenoid shut-off of the gas) . In case of alarm PARKING-EN, the minimum is 60 sec.,
but only for the relay set for the threshold 3 .
(5)
NOTA
Normally leave ZERO. It is used only to enable devices that must remain in operation more than alarm. This
function can not be used together with the function Time ON and you can not select YES the Larched Output.
(6)
Normally leave ZERO. This function can not be used together with the function Hysteresis OFF and you can not
NOTA
select YES the Larched Output.
(7)
The Output Latched is set YES only if Hysteresis OFF or Time ON are set to ZERO. Normally should be set to
NOTA
YES to prevent the resetting of an actuator (eg. Solenoid shut-off of the gas) without first verifying that the Central is
in alarm.
TECNOCONTROL S.r.l. - Via Miglioli, 47 20090 SEGRATE (MI) - Tel. 02. 26 92 28 90 - Fax 02. 21 33 734
CE424P / User Manual
