IST-1424.CE02.02
Please read and keep care of this manual and the manual of
installed sensors too.
All documentation relating to gas detection plant should be preserved, because it contains
the procedures to be used during the routines verification and / or during the periodic
calibration. We recommend that you always complete the Setup Memorandum Tables
last pages of this
manual. This will facilitate any possible change to the configuration and/or
in case of additional sensors, and operations and maintenance service
The CE424 is a control unit for gas alarm systems up to 24 independent detection points. The
simple installation and easy configuration via the buttons make the unit suitable for use in
many areas, both civil and industrial.
It should be noted that inappropriate use or lack of maintenance can affect the
operation of the device and thus preventing the proper activation of alarms with
potential serious consequences for the user.
TECNOCONTROL disclaims any responsibility if the product is misused, altered or not as
planned or outside the rated operating limits or put in work incorrectly. The choice and use of
the product are the sole responsibility of the individual operator.
The rules, laws, etc.. mentioned, are the ones valid on the date of issue. In any case, must be
observed all applicable national regulations in the country of use.
The information contained in this document are accurate, current at the date of publication,
and are the result of continuous research and development, the specifications of this product
and what is indicated in this manual may be changed without notice.
The Central has a clock with the automatic DST change. In the absence of power
supply, the clock works with the lithium battery (on the board in the cover), its life, in
normal operation is over 5 years.
If the lithium battery is exhausted and the central remained completely without power, at
startup, you will need to enter the correct date and time
be replaced soon with a new one.
Control unit for 4 gas detectors, expandable up to 8 with 1 ES404. Equipped with # 5
CE424P
relay outputs expandable to 9 with 1 ES4014. The unit has also # 1 Logic
ES404
Expansion card with 4 inputs (4÷20mA) for gas detectors.
ES414
Expansion card with 4 relay outputs.
ES415
Expansion card with 1 RS485 serial port – Communication via Modbus RTU binary
Remote Unit CE380UR, with 8 input 4 to 20mA for gas detectors, which can be
RU
installed up to 2 expansion cards ES380UR, each with 4 relay outputs.
It is the name that, for simplicity, are indicated the various models of Remote Gas
SENSORS
Sensors, with current output 4 to 20mA, that can be connected to the CE424P.
FIRMWARE Program inserted into the microcontroller which controls CE424P functioning.
Symbol that indicates an important warning in the instructions.
Symbol indicates information or additional explanation in the instructions.
Documento / Document name:
Oggetto / Subject :
CE424P Wall mount Control Unit GIUGIARO design
Rev.
Data / Date
0
14/12/2016
TECNOCONTROL S.r.l. - Via Miglioli, 47 20090 SEGRATE (MI) - Tel. 02. 26 92 28 90 - Fax 02. 21 33 734
CE424P / User Manual
INFORMATION AND WARNINGS OF USE
NOTES FOR READING INSTRUCTION
IST-1424.CE02.02_CE424-EN (14.12.2016).docx
Da / By
Note
UT/FG
Document Edition
(see page
32) and then the battery must
Pag. 2/50
in the
Input.
