breakage. Stone and brick walls, curbs, and wood
may wear line rapidly.
Avoid trees and shrubs. Tree bark, wood mouldings,
■
siding, and fence posts can easily be damaged by
the string.
GRASS DEFLECTOR LINE TRIMMING CUT-OFF
BLADE
See Figure 11.
The trimmer is equipped with a line trimming cut-off blade
on the grass deflector. For best cutting, advance line until
it is trimmed to length by the cut-off blade. Advance the
line whenever you hear the engine running faster than
normal, or when trimming efficiency diminishes. This will
maintain best performance and keep the line long.

STARTING AND STOPPING

See Figures 13 - 14.
When starting the line trimmer for the first time or
when the battery voltage is low, it may be necessary to
manually start the string trimmer.
FOR MANUAL START:
To start a cold engine:
DO NOT squeeze the throttle trigger until the engine
■
starts and runs.
Lay the trimmer on a flat, level surface.
■
PRIME - Press the primer bulb at least 7 times, so
■
fuel is clearly visible.
SET the start lever to the START position.
■
Ensure the 'Ignition switch' (item 6) is in the centre
■
position.
PULL the recoil starter until the engine starts.
■
Wait 6-10 seconds, then gently squeeze the trigger to
■
run.
NOTE: Squeezing and releasing the throttle trigger
releases the start lever to the RUN position.
To start a warm engine:
Make sure the 'ignition switch' is in the centre
■
position.
PULL the recoil starter until the engine starts.
■
To stop the engine:
Press the 'ignition switch' (item 6) to the stop " O "
■
position and the engine will stop.
FOR ELECTRIC START: RBC30SET - ONLY
MAKE SURE THE BATTERY HAS BEEN FULLY
CHARGED - SEE CHARGING BATTERY
To start a cold engine:
DO NOT squeeze the throttle trigger until the engine
■
starts and runs.
Install the battery onto the unit as shown in figure 8.
■
Lay the trimmer on a flat, level surface.
■
PRIME - Press the primer bulb at least 7 times, so
■
fuel is clearly visible.
SET the start lever (item 20) to the START position
■
NL S DK N FIN GR HU
English
■
■
■
■
■
NOTE: Squeezing and releasing the throttle trigger
releases the start lever to the RUN position.
To start a warm engine:
■
■
■
FOR ELECTRIC START RBC30SBT - ONLY
To start a cold engine:
■
■
■
■
■
■
■
■
■
■
NOTE: Squeezing and releasing the throttle trigger
releases the start lever to the RUN position.
To start a warm engine:
■
■
■
26
CZ RU RO PL SLO HR TR EST LT
on the side of the carburettor.
PRESS the 'safety switch' (item 18) and the 'ignition
switch' to position 3 (item 6) at the same time.
N.B. The safety switch is a rocker type switch and will
automatically reset it's self once released.
N.B. The ignition switch is a 3 position switch. position
1 is 'off' ("0") position 2 is run, and position 3 ("I") is a
rocker type switch which will automatically reset it's
self to position 2 once released.
RELEASE the 2 switches after engine starts - they
will revert back to their resting place.
Wait 6-10 seconds, then squeeze the throttle trigger
to run.
Lay the trimmer on a flat, bare surface.
PRESS the 'safety switch' (item 18) and the 'ignition
switch' (Item 6) at the same time.
RELEASE the 2 switches after engine starts - they
will revert back to their resting place.
DO NOT squeeze the throttle trigger until the engine
starts and runs.
Install the battery onto the unit as shown in figure 8.
Lay the trimmer on a flat, level surface.
PRIME - Press the primer bulb at least 7 times, so
fuel is clearly visible.
SET the start lever (item 20) to the START position
on the side of the carburettor.
PRESS the 'safety switch' (item 18) and the 'ignition
switch' to position 3 (item 6) at the same time.
N.B. The safety switch is a rocker type switch and will
automatically reset it's self once released.
N.B. The ignition switch is a 3 position switch. position
1 is 'off' ("0") position 2 is run, and position 3 ("I") is a
rocker type switch which will automatically reset it's
self to position 2 once released.
RELEASE the 2 switches after engine starts - they
will revert back to their resting place.
Wait 6-10 seconds, then squeeze the throttle trigger
to run.
Lay the trimmer on a flat, bare surface.
PRESS the 'safety switch' (item 18) and the 'ignition
switch' (Item 6) at the same time.
RELEASE the 2 switches after engine starts - they
will revert back to their resting place.
