GB
F D E I P
moulded into one side of the handle.
Reinstall the bracket.
■
Tighten screws securely.
■
RBC30SBT
NOTE: The throttle trigger must be mounted to the
operator's right side.
Remove the bracket (item 31)
■
Place the handle in the clamp located on the shaft
■
housing.
Reinsert the bracket into the mounting fixture
■
Adjust the handle bar for best operator control in a
■
comfortable upright position.
Tighten wing knob to hold the bike handle securely.
■
ATTACHING THE GRASS DEFLECTOR
See Figure 5.
Attach the blade guard to the mounting bracket;
■
install the four screws from the top of the mounting
bracket through the blade guard and into the threaded
mounting plates.
Using the torx wrench supplied, tighten all four screws
■
securely.
NOTE: When using the string head, the grass deflector
must be attached to the blade guard..
Attach the grass deflector to the blade guard by
■
placing the three locking tabs into the three notches.
Snap the blade guard and grass deflector together to
■
lock into place.
WARNING
Always stop the engine and remove the spark
plug wire before making any adjustments such
as changing cutting heads; this is to reduce the
risk of serious personal injury.
ATTACHING THE SHOULDER STRAP
See Figure 6.
Note: Always use the shoulder strap/harness with your
brushcutter.
RBC30SET
Follow these steps to attach the shoulder strap.
Connect the latch on the strap to the hanger bracket.
■
Adjust the strap to a comfortable position.
■
RBC30SBT
Follow these steps to attach the shoulder strap.
Connect the latch on the shoulder harness to the
■
strap hanger.
Adjust the strap to a comfortable position.
■
FEATURES
PRODUCT SPECIFICATIONS
Engine Displacement ...........................................30 cm³
Cutting Path Diameter ...............................18 in / 457mm.
NL S DK N FIN GR HU
English
String Diameter...................................................2.41 mm.
Blade Diameter......................................................200mm.
Battery Voltage........................................................12 Volt
Mass (without fuel, cutting attachment
and guard)......................................... RBC30SET: 6.37 kg
Mass
(without fuel with string head)................RBC30SET: 6.7kg
Mass
(without fuel, with blade head).............RBC30SET: 6.65kg
Volume (fuel tank)..................................................415cm³
Maximum engine perform
(in accordance with ISO8893)................................0.70kW
Maximum rotational
frequency of the spindle ...................................10000/min
Engine speed (rotational frequency) at recommended
max. spindle rotational frequency......................12000/min
Engine speed (rotational frequency)
at idling.......................................................2800-3800/min
Fuel consumption (in accordance with ISO8893)
at max. engine performance..............0.48kg/h or 0.66 L/h
Specific fuel consumption (in accordance with ISO8893)
at max. engine
performance.............................640 g/kW.h or 0.87 L/kW.h
Vibration levels for idling and racing
(for idling and with wide open throttle for grass trimmers)
when measured in accordance with 4.2 Vibration level
idling for Left handle Right and
handle .............................................3.3 m/s² and 3.6 m/s²
when measured in accordance with 4.2 Vibration level
idling for Front handle and Rear
handle............................................. 3.5 m/s² and 3.3 m/s²
Vibration level racing for Left handle and Right
handle........................................... 3.9 m/s² and 10.5 m/s²
Vibration level racing for Front handle and Rear
handle......................................... 14.5 m/s² and 10.4 m/s²
Sound pressure level (in accordance
with EN27917)................................RBC30SET: 92 dB (A)
Sound power level (in accordance
with ISO10884).............................. RBC30SET:112 dB (A)
KNOW YOUR BRUSHCUTTER
See Figure 1.
The safe use of this product requires an understanding of
the information on the tool and in this operator's manual
as well as a knowledge of the project you are attempting.
Before use of this product, familiarise yourself with all
operating features and safety rules.
The charger has a key-hole hanging feature for
convenient, space-saving storage. Screws should be
installed so that the centre distance is 11.5cm
22
CZ RU RO PL SLO HR TR EST LT LV SK BG
RBC30SBT: 7.07 kg
RBC30SBT: 7.4kg
RBC30SBT: 7.35kg
RBC30SBT: 90 dB (A)
RBC30SBT:110 dB (A)
