Picture 16 - Terminal board for the connection to the network: 1. Line 2. Neutral 3. Earth.
2.14 WOODBOX EXTRACTION
To remove the woodbox it is necessary to extract
the woodbox to limit switch, remove the two
thumbscrews that keep it fixed to the sliding rails.
When the box is free, it can be lifted and extract-
Picture 17 – Woodbox extraction.
1
2
3
77
ed. To reinsert the woodbox repeat the operations
in the opposite sense paying attention to insert
correctly the woodbox in the sliding rails.
