This product is powered by a 2-stroke engine and
requires pre-mixing petrol and 2-stroke lubricant. Pre-mix
unleaded petrol and 2-stroke engine lubricant in a clean
container approved for petrol.
This engine is certified to operate on unleaded petrol
intended for automotive use with an octane rating of 91
or higher.
Do not use any type of pre-mixed petrol/lubricant from
fuel service stations; this includes the pre-mixed petrol/
lubricant intended for use in mopeds, motorcycles, etc.
Use a high quality 2-stroke self-mixing lubricant for air-
cooled engines. Do not use automotive lubricant or
2-stroke outboard lubricant.
Mix 2% lubricant into the petrol. This is a 50:1 ratio.
Mix the fuel thoroughly and each time before fuelling.
Mix in small quantities. Do not mix quantities larger than
usable in a 30-day period. A 2-stroke lubricant containing
a fuel stabilizer is recommended.

FUEL MIXTURE

This product is powered by a 2-cycle engine and requires
pre-mixing petrol and 2-cycle lubricant. Pre-mix unleaded
petrol and 2-cycle engine lubricant in a clean 1 gallon
container approved for petrol.
Recommended fuel: This engine is certified to operate on
unleaded petrol intended for automotive use.
Mix a high quality 2-cycle engine lubricant at 100ml per
5L of petrol.
Do not use automotive lubricant or 2-cycle outboard
-lubricant.
DO NOT mix quantities larger than usable in a 30 day
period.
HIGH QUALITY 2-CYCLE ENGINE LUBRICANT
1 litre +
2 litres +
3 litres +
4 litres +
5 litres +
FILLING TANK
Clean surface around fuel cap to prevent
Q
contamination.
Loosen fuel cap slowly. Rest the cap on a clean
Q
surface.
Carefully pour fuel into the tank. Avoid spillage.
Q
Prior to replacing the fuel cap, clean and inspect the
Q
gasket.
IT PT NL SV DA
English (original instructions)
20 ml = 50: 1
}
40 ml = 50: 1
60 ml = 50: 1
80 ml = 50: 1
100 ml = 50: 1
NO FI HU CS RU
Immediately replace fuel cap and hand tighten. Wipe
Q
up any fuel spillage.
NOTE: It is normal for smoke to be emitted from a new
engine after first use.
WARNING:
Always shut off engine before fuelling. Never add
fuel to a machine with a running or hot engine.
Move at least 10m from refuelling site before
VWDUWLQJ HQJLQH 'R QRW VPRNH )DLOXUH WR KHHG
this warning could result in serious personal
injury.
CAUTION:
If at any point during the charging process none
of the LEDs are lit, remove the battery pack from
the charger to avoid damaging the product. DO
NOT insert another battery. Return the charger
and battery to your nearest service centre for
service or replacement.

CHARGING THE BATTERY PACK

The battery pack for this tool has been shipped in a
low charge condition to prevent possible problems.
Therefore, you should charge overnight prior to use.
NOTE: Batteries will not reach full charge the first
time they are charged. Allow several cycles (operation
followed by recharging) for them to become fully charged.
Charge battery pack only with the charging assembly
Q
provided (BPH-1215 / 12V Ni-Cd).
Make sure power supply is normal household
Q
voltage, 220V~ to 240V~, 50 Hz.
Connect charger to power supply.
Q
Place battery pack in charging stand. Align raised rib
Q
on battery pack with groove in charging stand. See
Figure 7.
Press down on battery pack to be sure contacts
Q
on battery pack engage properly with contacts in
charging stand.
The charge indicator light (LED), located on the
Q
charging stand, will light up red and glow when the
charger is properly connected to power supply. This
light indicates the charger is operating properly. It
will remain on until battery pack is removed from
charging stand or charger is disconnected from
power supply.
After normal usage, 3 hours or less of charging time
Q
is required to fully recharge battery pack.
If both red and orange LED indicators glow, the
Q
battery pack is deeply or completely discharged, and
6 hours or longer of charging time is required to fully
recharge battery pack.
NOTE: If charger does not charge battery pack
or orange LED continues to glow after more than 30
minutes of charging, return battery pack and charging
assembly to your nearest Ryobi Authorised Service
Centre for electrical check.
