NOTE: The throttle trigger must be mounted to the
operator's right side.
Remove the bracket (item 31)
Q
Place the handle in the bracket (33) located on the
Q
shaft housing.
Hold the stamping clamp (31) and align the bolts (32)
Q
into the the bracket (33).
Adjust the handle bar for best operator control in a
Q
comfortable upright position.
Tighten bolts (32) with the stamping wrench to hold
Q
the bike handle securely.
ATTACHING THE BLADE AND GRASS DEFLECTOR
See Figure 5.
1. Attach the grass deflector to the blade deflector and
align the 3 screws on the grass deflector to the
screw holes on the blade deflector.
2. Using the combination wrench supplied, tighten all 3
bolts securely.
3. Attach the Blade deflector to the mounting bracket
and align the screw holes on the Blade deflector to
the screws on the mounting bracket.
4. Using the combination wrench supplied, tighten all
two bolts securely.
:$51,1*
When using the brush cutter blade, the grass
deflector (21) must be removed from blade
deflector (16) , When using the line trimmer
string head, the grass deflector (21) must be
attached to the blade deflector (16).
WARNING
Always stop the engine and remove the spark
plug wire before making any adjustments such
as changing cutting heads; this is to reduce the
risk of serious personal injury.
INSTALLING REEL EASY STRING HEAD
See Figure 5.
Open the Reel Easy Line Trimmer Head by
Q
depressing the latches on each side. The contents of
the line trimmer head are spring loaded, so keep your
other hand over the line trimmer head cover while
depressing the latches.
Remove the line trimmer head cover, knob, and spool
Q
and set aside.
Place the line trimmer head on the drive shaft. Make
Q
sure the line trimmer head is fully seated.
Install the hex bolt into the opening on the drive shaft
Q
and secure using the hex-shaped opening in the
knob to tighten.
IT PT NL SV DA
English (original instructions)
NO FI HU CS RU
NOTE: Only use the knob to tighten the bolt. The use
of other tools may allow over tightening of the bolt,
which could damage the line trimmer head.
Reinstall the spring into the line trimmer head and
Q
push down to seat.
Reinstall the spool. For the RLT30CES curved line
Q
trimmer attachment, the spool should be placed so
"This side out for curved shaft" is visible. If you are
using a straight shaft attachment with the Reel Easy
cutting head the spool should be placed so "This side
out for straight shaft" is visible.
Replace the knob in the spool.
Q
Replace the line trimmer head cover, aligning latches
Q
with openings in the line trimmer head. Press cover
and line trimmer head together until both latches
snap into openings securely.
Install line as described in the next section of this
Q
manual.
ATTACHING THE SHOULDER STRAP
See Figure 6.
Note: Always use the shoulder strap/harness with your
brushcutter.
RBC30SET
Follow these steps to attach the shoulder strap.
Connect the latch on the strap to the hanger bracket.
Q
Adjust the strap to a comfortable position.
Q
RBC30SBT
Follow these steps to attach the shoulder strap.
Connect the latch on the shoulder harness to the
Q
strap hanger.
Adjust the strap to a comfortable position.
Q
FEATURES
PRODUCT SPECIFICATIONS
Engine Displacement ...........................................30 cm³
Cutting Path Diameter ...............................18 in / 457mm.
String Diameter...................................................2.41 mm.
Blade Diameter......................................................200mm.
Battery Voltage........................................................12 Volt
Mass (without fuel, cutting attachment
and guard)......................................... RBC30SET: 6.37 kg
Mass
(without fuel with string head)................RBC30SET: 6.7kg
Mass
(without fuel, with blade head).............RBC30SET: 6.65kg
Volume (fuel tank)..................................................415cm³
Maximum engine perform
(in accordance with ISO8893)................................0.70kW
Maximum rotational
frequency of the spindle ...................................10000/min
