Encoder connection: round plug (8−pin, 6 è Fig. 1)
Pin Allocation
1 Signal trace A
2 Signal trace A/
3 Signal trace B
4 Signal trace B/
5 GND encoder
6 Signal trace N
7 Signal trace N
8 VCC auxiliary supply 5 V
1) Only for motors with encoder ERMO−...−ST-E
Tab. 4
