BFT RIGEL 5 Instructions D'utilisation Et D'installation page 22

10.1) TABLE A: PARAMETERS MENU (PARA )
Parameter min. max.
3 sec. 120 sec.
TCA
v o r k . t .
3 sec. 180 sec.
ot. 1
v o r k . t .
3 sec. 180 sec.
ot. 2
3 sec. 9 sec.
ped. t.
open delay
0 sec. 10 sec.
ti e
c l s d e l a y
0 sec. 60 sec.
ti e
slov -
0 sec. 20 sec.
dovn t.
0 sec. 30 sec.
clear. t
0% 99%
preheat.
slovd
1% 99%
torque
1% 99%
ot. torque
0% 99%
brake
0% 99%
e er. brake
0 127
Zone
10.2) TABLE B: LOGIC MENU (logic)
Logic Default Definition
Automatic
OFF
TCA
Closing Time
Opening Impul-
OFF
Ibl open
se lock
I mpulse lo ck
OFF
ibl TCA
TCA
Impulse lock on
OFF
bl close
closing
Ram blow on
ra blov
OFF
opening
c. o p
R a m b l ow i n
ra blov
OFF
closing
c. c l
2-step, 4-step
OFF
2 step
logic
OFF 3-step logic
3 step
OFF Pre alarm
pre-alar
bloc
OFF Lock hold
persist
hold-to-
OFF Hold-to-run
run
22 -
RIGEL 5
INSTALLATION MANUAL
default personal Definition
Automatic Closing Time
40
60 Operation time motor 1
Operation time motor 2
60
Pedestrian operation time
6
Opening delay time for leaf 1
3
Closing delay time for leaf 2
3
Slow-down time
0
Traffic-light area clearance
15
time
Preheating
30%
Slowdown Motor Torque
50%
Motor torque
50%
0% Braking
Emergency braking
60%
0 Zona
Cross out
setting Description
used
ON Switches automatic closing on.
OFF Switches automatic closing off.
ON The Start impulse has no effect during the opening phase.
OFF The Start impulse becomes effective during the opening phase.
ON The Start impulse has no effect during the TCA dwell period.
OFF The Start impulse becomes effective during the TCA dwell period.
ON The start impulse has no effect during the closing stage.
OFF The start impulse is effective during the closing stage.
It pushes for approx. 2 seconds in closing direction before opening. This allows the electric lock to be released
more easily (not affected by limit switches). IMPORTANT - When no adequate mechanical backstops are
ON
installed, do not use this function. It is also to be absolutely avoided in the automation of sliding gates.
OFF Excludes the ram blow in closing.
Before carrying out the closing manoeuvre, the gate pushes for about 2 seconds on opening. This allows the
electric lock to be released more easily.(not affected by limit switches)
ON
IMPORTANT - When no adequate mechanical backstops are installed, do not use this function. It is also to be
absolutely avoided in the automation of sliding gates.
OFF Excludes the ram blow in closing.
ON Enables 2-step logic (prevails over "3-step logic").
OFF Enables 4-step logic when the 3-step logic is set to OFF.
ON Enables 3-step logic (with 2 steps=OFF).
OFF Disables 3-step logic.
The blinker comes on about 3 seconds before the motor
ON
starts.
The blinker comes on at the same time as the motor
OFF
starts.
If the motors remain still in a totally open or closed position for over one hour, they are activated for about 3
seconds in the respective direction. This operation takes place once every hour.
N.B.: This function has the purpose of compensating any oil volume decrease in the hydraulic motors, due to
ON
a temperature drop during prolonged pauses, for instance at night, or to internal leaks.
IMPORTANT - When no adequate mechanical backstops are installed, do not use this function. It is also to be
absolutely avoided in the automation of sliding gates.
OFF Exclude block maintenance.
Hold-to-run operation: the manoeuvre continues as long as the command key is kept pressed.
ON
IMPORTANT - It is not possible to use the radio transmitter.
OFF Impulse operation.
Description
Set the numerical value of the TCA automatic closing time from 3 to 120
seconds.
Enter the numerical value corresponding to the working time from 3 to 180
seconds for motor 1.
Enter the numerical value corresponding to the working time from 3 to 180
seconds for motor 2.
Set the pedestrian opening time of motor 2 from 3 to 90 seconds.
Set the opening delay time for motor 1 with respect to motor 2, which can
be adjusted from 0 to 10 seconds.
Set the closing delay time for motor 2, which can be adjusted from 0 to
60 seconds.
Set the slow-down to approach time from 0 to 20 seconds. The slow-down
time is subtracted from the work time.
NOTE: it is advised to activate timing.
NOTE: only use this function when limit switches are fitted.
NOTE: Do not use with hydraulic motors.
Set the required clearance time for the area involved in the traffic governed
by traffic light, from 0 to 30 seconds. Set to 0 if not used.
Set the percentage value of the current from 0 (deactivated pre-heating) to
99% which can be made to pass through the motor windings to keep them
at the right temperature.
NOTE: Only with SSR5.
Set numerically from 1% to 99% the value of motor torque during slowdown
time.
Set the numerical torque value from 1 to 99%.
NOTE: When using with oil-hydraulic motors, it is necessary to set the
torque value to 99% and adjust the force directly on the motor.
Set the braking value from 0% (min.) to 99% (max.) according to the gate
weight and the mechanical demands involved.
Set the value of the emergency braking from 0% (min.) to 99% (max.). This
is carried out by enabling the safety commands on the inputs 34 (block),
37 (SAFE OP) and 55 (SAFE CL).
Enter the zone number between 0 (minimum value) and 127 (maximum
value). See paragraph "SCS OPTIONAL MODULES".
A start impulse has the following effects:
closed
on closing
open
on opening
after stopping closes
2 step 3 step 4 step
opens
opens opens
stop
closes closes
closes
stop + TCA stop + TCA
opens opens
