Installation instructions, only for experts

8.2. Humidity module WC4-H-PCB (optional)

Supply
Power consumption
Fuse
Ambient conditions
Casing
Fastening
Dimensions: L x W x D
Weight

8.3. Operating unit

Connection
Power consumption
Temperature
T i m e i n t e r v a l / e l .
hourglass
Light dimmer
Humidity operation (op-
tional)
Ambient conditions
Casing
Fastening
Dimensions: L x W x D
Weight
3-pole with L1, N ,PE
12 V= / ~20 mA normal operation (~0.3 W)
4 A slow for the ventilator outlet
0 °C – 50 °C, max. 95 % rel. humidity, not condensing
Open board in casing of power unit
Board via M3 bolts on carrier plate
80 x 60 x 25 mm
~100 g unpacked
4-pole with supply and communication cables
5 V= / < 100 mA normal operation (< 0.5 W)
Display of actual and target temperature 30 °C to
110 °C (+/- 1 °C) according to programme
0 to 99 minutes with bleeper which can be switched off
0 % to 100 % (+/- 2 %) for up to 100 W
Display of actual and target humidity 0 % to 80 %
rel. h. (+/- 5 %) according to programme
0 °C – 110 °C, max. 99 % rel. humidity, not con-
densing
Mounting box; board; light conductor for display;
wooden front with temperature-resistant film
Board via M2, 5 bolts on wooden front; reverse with
mounting box
120 x 92 x 44,5 mm
~ 212 g without cable and unpacked
