Errebi DAKAR EVOLUTION Notice D'utilisation page 11

1.- PRESENTATION AND GENERAL ASPECTS
1.1 GEnERal pOInTS
1.2 TRanSpORT anD pacKInG
1.3 IDEnTIFIcaTIOn laBEl
2. - CHARACTERISTICS OF THE MACHINE
2.1 FamIlIES OF KEYS
2.2 accESSORIES
2.3 TOOl STORE
2.4 ElEcTRIc cIRcuIT
2.5 TEchnIcal DaTa
2.6 maIn ElEmEnTS OF ThE machInE
2.7 cOmpOnEnTS anD FuncTIOnal paRTS
2.7.1 chanGInG ThE cuTTER anD TRacER pOInT (21)
2.7.2 BlOcKInG ThE SlIDE aT ThE EnD OF ThE "Y" aXIS TRaVEl
2.7.3 clamp (6)
2.7.4 TRacER pOInT SpRInG mEchanISm (11)
2.7.5 SpRInG mEchanISm anD BlOcKInG ThE SlIDE On ThE "X" aXIS (5 anD 4)
2.7.6 SuppORT lEVER FOR TuBulaR KEYS
2.7.7 cuTTER SpEED (17)
2.7.8 KEYpaD-DISplaY (1)
2.7.9 VERTIcal aDJuSTmEnT OF ThE TRacER pOInT (15)
2.7.10 cOnTROl OF cuTTInG FORcE
3.- CUTTING
3.1 cuTTInG pROcESS
3.2 KEY cuTTInG
3.2.1 KB2, KB4 anD KB5 KEYS
3.2.2 Kc1 KEY
3.2.3 SE1l KEY
3.2.4 hF42p15 anD Ym22p15 KEYS
3.2.5 hF40p18 anD hF38p17 KEYS
3.2.6 TuBulaR KEYS
3.2.7 Fc6 anD Fc120 KEYS
3.2.8 TK23, TK24 anD TK25 KEYS
3.2.9 JIS4p KEY
3.2.10 TB1p5KEY
3.2.11 mD13R KEY
3.2.12 TS14 anD TS12 KEYS
4.- MAINTENANCE
4.1 REplacInG ThE clamp JaWS
4.2 aDJuSTInG ThE JaWS
4.2.1 nORmal aDJuSTmEnT
4.2.2 pREcISIOn aDJuSTmEnT
4.3 REplacInG ThE FuSES
4.4 TIGhTEnInG anD REplacInG ThE BElT
4.5 REplacInG ThE mOTOR
4.6 REplacInG ThE KEYpaD-DISplaY
4.7 REplacInG ThE ElEcTROnIc cOnTROl caRD
4.8 REplacInG ThE pOWER caRD anD cIRcuIT BREaKER
5.- SAFETY
6.- WASTE DISPOSAL
6.1 pacKInG
6.2 SWaRF
6.3 machInE
7.- KEY-CUTTER-TRACER POINT-ANGLE CUT-ADAPTOR TABLE
8.- EXPLODED VIEW
