USE AND MAINTENANCE
1.6 ASSEMBLY DRAWING
(Fig. 3)
1) Seed hopper;
2) Fan;
3) Seed distributor;
4) Gearbox;
5) Drive wheel;
6) a) Spike furrow opener;
b) Double disc coulter;
11
7) Footboard;
8) Tranks remover;
9) Hydraulic row marker;
10)Seed covering harrow;
11) Bearing wheel for floating frame;
12)Nitrogen accumulator;
13)Warning boards and light kit;
14)Identification plate.
4
6a
6b
14
8
12
5
1
9
7
13
3
2
10
fig. 3
g
cod. G19503100
