Siemens SIMOVERT MASTERDRIVES Motion Control Instructions De Service page 297

08.2008
Designation
Order number 6SE70...
Rated voltage
Input
Output
Rated frequency
Input
Output
Rated current
Input
Output
DC link voltage
Rated output [kVA]
Aux. power supply
Pulse frequency [kHz]
Derating curve
Load class II acc. to EN60146-1-1:
Base load current
Overload current
Cycle time
Overload duration
Losses, cooling, power factor
Power factor
Line cosϕ1N
Converter cosϕU
Efficiency η
Pulse frequency 5 kHz
Dissipated losses [kW]
Pulse frequency 5 kHz
Cooling air required [m³/s]
Sound pressure level, dimensions, weights
Sound pressure level [dB(A)]
Type of construction
Width
Height [mm]
Depth
Weight
Siemens AG 6SE7087-7JK50
SIMOVERT MASTERDRIVES
31-0EE 0 31-2EF 0
[V]
3 AC 380 to 480 (-15 % / +10 %)
3 AC 0 ... rated input voltage x 0.86
[Hz]
[A]
101 136
92 124
[V]
61...76 82...103
[V] DC 24 (20 -30) (3.0 A without options; more with options)
5.0 – 10.0 5.0 – 10.0
0.91 x rated output current
> 0.98 > 0.98
< 0.92 ind. < 0.92 ind.
0.97 0.97
1.38 1.83
0.10 0.14
69 69
E F
270 360
1050 1050
350 350
[kg] 55 65
*) With Z = F02; 2.5 kHz pulse frequency
= 5 corresponds to MASTERDRIVES Motion Control
= 7 corresponds to MASTERDRIVES Motion Control Performance 2
Operating Instructions
Value
31-8EF 0 32-1EG 0
50/60 ± 6 %
0 ... 400
171 192
155 175
186 *) 210 *)
510 ... 650
102...128 115...145
5.0 – 9.0 5.0 – 7.5
5.0 – 6.0 *)
1.6 x rated output current
300 s
30 s
> 0.98 > 0.98
< 0.92 ind. < 0.92 ind.
0.97 0.98
2.43 2.77
0.14 0.31
69 80
F
360 508
1050 1450
350 350
65 155
Technical Data
32-6EG 0
238
218
260 *)
143...181
5.0 – 7.5
> 0.98
< 0.92 ind.
0.98
3.45
0.31
80
G G
508
1450
460
155
11-5
