sigfox RC1 ANALOG - Guide utilisateur / User guide version V2.0.1
3.2.2

Command mode

Use a COM port terminal in order to communicate with the device. We use the HERCULES COM port soft terminal available to download for free
by clicking on the following link: https://www.hw-group.com/products/hercules/index_en.html
• With Hercules, select the "Serial" tab, then configure the serial port with the following serial parameters:
Parameters
Rate
Parity
Data
Stop Bit
• Select the serial port on which the device has been created with Windows (Name).
• Click on the "Open" button to open the serial port.
NOTE INFORMATION :If the com port has been opened correctly, Hercules will display the message "Serial
COM3 port opened".
Alternatively, "Serial port com opening error" will be displayed, meaning either that the com port is already open for another application, or it
does not exist.
Write '+++' to execute the configuration mode..
On the com port terminal, you should also have «CONNECTING...» and « CM »
feedback for Command Mode.
Sending a character on Hercules is displayed in magenta and receiving a character
is displayed in black. If you do not see sending characters, this is probably because
ECHO is not active on this program. To activate the option in the accessible menu,
right click in the viewing window.
VALUE
115 200 bps
None
8
1
FR
EN
