In the example in grey this gives:
• Byte 2=0x02: register 320, channel A configured for a 4-20mA sensor
• Bytes 3 to 5=0x0C3500=800,000 in decimal i.e. A value measured on channel A of: 800,000,x10=8,000,-
000nA i.e. 8mA
• Byte 6=0x01: register 322, channel B configured for a 0-10V sensor
• Bytes 7 to 9=0x4C4B40=5,000,000 in decimal i.e. a value measured on channel B of: 5,000,000 µV i.e. 5V
4.1.5

Reply frame to a register value request in a downlink frame

Following reception of a downlink frame with the code 0x40, the frame 0x31 is transmitted.
It contains all the values of the registers requested in the downlink frame 0x40.
• Frame (0x40) sent to the product (downlink) :
0 1
Code
0x40 CONF ID1
The CONF IDX (8bits) fields represent the index of the registers to be sent. The corresponding register is 300 +
CONF IDX value.
• Response frame (0x31) from the product:
0 1
Code Cf. Status
VALUE1
0x31 Status
In this example: CONF ID1 is a 2-byte register, CONF ID2 a 1-byte register and CONF ID3 a 2-byte register.
If an error is detected in the request, the returned 0x31 frame will be empty.
4.1.6

Data Frame

This frame (0x42) contains the values measured on the different sensors
0 1 2
Code Status PAYLOAD
0x42 Cf Status S320
0x42 0xA2 0x02
Description de la trame :
• Byte 2: Type of the sensor on channel A. Configured by the user (register 320).
• Bytes 3 to 5: Value measured on channel A.
• If the type of sensor is 0-10V: The value is expressed in µV
• If the type of sensor is 4-20mA: The value is expressed in nA
• Byte 6: Type of the sensor on channel B. Configured by the user (register 322).
• Bytes 7 to 9: Value measured on channel B.
• If the type of sensor is 0-10V: The value is expressed in µV
• If the type of sensor is 4-20mA: The value is expressed in nA
In the example in grey this gives:
• Byte 2=0x02: register 320, channel A configured for a 4-20mA sensor
• Bytes 3 to 5=0x0C3500=800,000 in decimal i.e. A value measured on channel A of: 800,000,x10=8,000,-
000nA i.e. 8mA
• Byte 6=0x01: register 322, channel B configured for a 0-10V sensor
2 3 4
PAYLOAD
CONF
CONF ID3 X
ID2
2 3 4
VALUE1 VALUE2
3 4
Valeur lue sur le capteur voie
A
0x0C3500
5 ...
X X
5 ...
PAYLOAD
VALUE3 VALUE3
5 6
S322
0x01
7
CONF ID7
11
X
7 8 9
Valeur lue sur le capteur voie
B
0x4C4B40
