5
The cover plate kit contains the following
parts for converting the power tool:
4 Cover plate partially blanks off the
slots in the starter housing
5 Synthetic fabric filter element for the
air filter
Instructions for converting the
–
machine
After installing the cover plate kit:
Set the shutter (2) to the winter
N
position.
At temperatures above -10 °C
Remove the parts of the cover plate
N
kit and refit the standard parts for
summer operation.
Depending on the ambient temperature:
Set the shutter (2) to the summer or
N
winter position.
Cleaning the Air Filter
Loosen filter cover mounting
N
screws.
Remove the filter cover.
N
Clean away loose dirt from around
N
the filter (5) and inside the filter
cover.
FS 510 C-M, FS 560 C-M
Knock the filter (5) out on the palm
N
2
of your hand or blow it clear with
compressed air from the inside
outwards.
In case of stubborn dirt or sticky filter
fabric:
4
Wash the filter in a clean, non-
N
flammable solution (e.g. warm
soapy water) and then dry.
Always replace a damaged filter.

Spark Plug

If the engine is down on power,
N
difficult to start or runs poorly at idle
speed, first check the spark plug.
Fit a new spark plug after about 100
N
operating hours – or sooner if the
electrodes are badly eroded. Install
only suppressed spark plugs of the
type approved by STIHL – see
"Specifications".
Removing the Spark Plug
1
Rotate the screw (1) in the cap (2)
N
until the screw head projects from it.
3
Lift the front of the cap (2) and push
N
it to the rear to disengage.
Put the cap to one side.
N
Remove the spark plug boot (3).
N
Unscrew the spark plug.
N
English
35
