Transport

Remove mains plug before each
transport.
The saw must only be transported with the saw blade
lowered and the protective cover in position.
This will avoid possible injury from the saw blade.
Take hold on the right and left side of the saw for
transporting.
If the saw is transported in a vehicle, it must be secured
against slipping and tilting. Avoid heavy vibration during
transport.
Never use the safety devices for handling and transport.
Before each fault clearance
− switch off device
− wait for stop of chain saw
− pull out main plug
After each fault clearance, put into operation and recheck all security installations.
Fault
Machine fails to start after
switching on or switches off
during idle running
Machine stops while cutting
Workpiece sticks when feeding
Burned spots at the cut areas
Chip outlet is clogged
Motor running, saw blade will not
turn.
Saw vibrates
In case of further faults or inquiries please contact your local dealer.

Possible faults

Possible cause
• Power failure
• Extension cable defect
• Motor or switch defect
• Saw blade sticks
• Saw blade blunt
• Feed is too great
• Saw blade is dull
• The longitudinal or parallel stop is not
parallel to the saw blade
• Saw blade is not suitable for the work step or
is dull
• No exhaust system connected
• Exhaust power too weak
• Driving belt defective
• Saw blade is warped
• Saw blade not properly mounted

Storage

Remove the mains plug from the socket.
Store unused equipment in a dry, locked place out of the
reach of children.
To extend the service life of the saw and guarantee smooth
operation, before storing for a longer period
− thoroughly clean the saw
− treat all movable parts with an environmentally friendly
oil
Never use any grease!
To save storage space, the saw frame can be collapsed.
Removal
• Replace fuse
• Check cable, no longer use defect cable
• Have motor or switch checked by an
approved electrician or replaced by original
spare parts
• Remove the cause of the jam.
• Replace saw blade
• Allow motor to cool and proceed working
with less pressure
• Hold the workpiece firmly and switch the
motor off immediately. The have the saw
blade sharpened or renew
•
Readjust the scale
• Replace saw blade or have it sharpened
• Switch off saw, remove chips and connect
exhaust system
• Switch off saw, remove chips and increase
exhaust power (air velocity 20 m/sec at chip
exhaust neck).
• Contact an authorised customer service
workshop
• Replace saw blade
• Mount saw blade properly
