Transceiver TIC - Guide utilisateur / User guide version V2.0.0

1.4. Technical Specifications

1.4.1 General characteristics

Parameters
Supply
Working temperature
Dimensions
Weight
Casing
LoRaWAN zone
Max power transmission
Applicative port (downlink)

1.4.2 Power supply

The LoRaWAN TIC has the great advantage of being able to provide its own power via the CIS or RS232 link, i.e. without using an internal
battery or an external power supply. It has an internal capacity to recover energy, the amount of recoverable energy (harvesting) depends on the
type of electricity meter and the configuration defined by the user.
Indeed, if the product is too often asked to scan labels and / or send data, it will not have time to collect enough energy.
The table below shows positively tested configurations with 2 types of counters:
Reference Type
Itron PME/PMI
ACE6000
(1200 bds)
Landis+Gyr
BLEU
ZMD126.02
(1200 bds)
Sagemcom Linky
LNE-29079 (1200 bds)
Landis+Gyr Linky
LNE-29125 (9600 bds)
IMPORTANT: The scan mode continues (register 320 = 0) is not possible without recourse to an external power supply or with the Linky supply
It is also important to note that when connecting to the meter an initial charging-time is required before the product becomes functional. This
time depends on the type of meter. To avoid this, the product has a USB connector that allows you to charge the product in seconds and an
external power input on its terminal block so you can use the product instantly without any time constraint waiting for the product to charge.
The table below shows positively tested configurations with 2 types of counters:
Reference
Itron ACE6000
Landis+Gyr ZMD126.02
Sagemcom LNE-29079
Landis+Gyr LNE-29125
Value
Directly by the CIS or RS232 link (harvesting)
or externally via:
• the micro-USB port (5V, 3000mA)
• the terminal block (6-36V continuous, 300mA)
-20°C / +60°C
187 x 50 x 27mm
102 grammes
IP 67
EU 863-870 MHz
14 dBm
1
LoRaWAN SF / data size in the frame
(bytes)
SF12 / 8
SF12 / 14
SF12 / 51
SF7 / 51
SF12 / 14
SF7 / 14
SF12 / 14
SF12 / 14
Type Charging mode
USB
PME/PMI (1200 bds)
None (pure harvesting)
USB
BLEU (1200 bds)
None (pure harvesting)
Linky None (pure harvesting)
Linky None (pure harvesting)
Polling period in minutes (regis-
ter 320)
1
1
1
1
1
1
continue
continue
Waiting time before the first transmission
16s
1h09min
16s
1hr 40min
13 min
12 min
Period of emission in minutes
(register 301)
5
6
10
1
6
1
1
1
