Figure 8 Plumb the instrument
1 Process pipe
2 Isolation valve, customer-supplied
3 Water inlet tubing, ¼-in. OD

User interface and navigation

After startup, the user interface shows the home screen. Refer to
4 Drain tubing, ¼-in.OD
5 Drain
Figure 9.
