2.2.2 Measurement cycle lights
The measurement cycle lights show the step of the measurement cycle being done. Refer to
Lights on
Description The cell is flushed with water. The buffer solution and the indicator
2.2.3 Analyzer status light
The analyzer status light changes from green to yellow when there is a warning or to red when there
is an error. Refer to Table
Color Description
Green Normal operation
Yellow The system needs attention to prevent a failure in the future. Measurements continue.
To show the warnings, push menu and select DIAGNOSTICS > [select analyzer] > WARNING LIST.
Refer to Warnings—Yellow light
Red The system needs immediate attention. Measurements have stopped.
To show the errors, push menu and select DIAGNOSTICS > [select analyzer] > ERROR LIST. Refer to
Errors—Red light

2.3 Product components

Make sure that all components have been received. Refer to
damaged, contact the manufacturer or a sales representative immediately.
Figure 2 Product components
1 CL17sc analyzer
2 Installation kit
Table 4 Measurement cycle lights
solution are added to the cell.
5.
Table 5 Analyzer status light
on page 24.
on page 24.
Figure 2. If any items are missing or
3 Tubing Kit (tubing harness and stir bar)
Table 4.
The sample is measured.
English 7
