ENGLISH
IMPORTANT: The instruction manual you are holding includes essential information on the safety measures to be implemented
for installation and start-up. Therefore, the installer as well as the user must read the instructions before beginning installation
and start-up.
Keep this manual for future reference.
To achieve optimum performance of the Irys projector, follow the instructions indicated below:
1. VERIFY THE CONTENTS OF THE PACKING:
The following accessories are included inside the box:
• Floodlamp unit
• Installation and maintenance manual

2. GENERAL CHARACTERISTICS:

This floodlamp has been designed to be used fully suomerged underwater in fresh water swimming pools. It is a Class III electric
apparatus with very low safety voltage (12 V with alternating current).
The floodlamp compiles with IPX8 degree of protectlon (resistance to penetratlon of dust, solld bodies and humidlty) at a nominal
Immersion depth of 2 m.
This floodlamp compiles with international safety standards for lights, especially the EN 60598-2-18 standard. LIGHTS PART 2:
SPECIFIC REQUIREMENTS SECTION 18 LIGHTS FOR SWIMMING POOLS AND SIMILAR APPLICATIONS.
The mains supply to the light should have 30 mA overload protection. The power supply transformer of these projectors must be an
insulated safety transformer with separate spooling.
The manufacturer is not responsible in any circumstances for assembly, installation or start-up of any eiectric components which
have been inserted or handied at locations other Ihan its own premises.
3. INSTALLATION:
• In order to clearly light a pool It Is recommended lo Install a floodlamp every 20 m² of water surface. In swimming pools which are
especialiy deep, a floodlamp is required for every 25 m³ of water volume.
• In order to prevent glare, the floodlamps shouid be installed so that they face away from the residence or usual view of the
swimming pool.
• In the event that lighting is used in training or competition pools, the floodlamps shouid be installed on the sides to prevent glare
on the swimmers.
• To avoid the need to empty the pool to change the lamp, we recommend that the floodlamp be insíailed in áreas which are
accessible from the upper edge of the pool.
• In installations where you want to replace a conventional spotlight by a LED projector, using the existing wiring, it is strongly
recommended to use underwater resin splicing. It is not recommended to use silicone to try to seal the connection point of the
wires. The spotlight should not be handled under any circumstances as this would lead to losing the guarantee.
Prior to installation verify that the gland seal (no. 24) has been fully tightened.
The floodlamp shouid be placed on the wall of the pool at approximately 400-700 mm from the water surface (Fig. 1).
The method of fastening the housing to the pool wall varíes depending on whether it is a floodlamp for concrete pools or
prefabricated pools.
This product is not supplied with the Recess Unit, which should be purchased separately. The code is 00349 for concrete pools and
00364 for prefabricated pools.
Concrete swimming pool
To install a floodlamp in a concrete swimming pool the housing shouid be fixed in the wall of the swimming pool (Fig. 2). Make sure
that the cable outlet of the housing remains on the upper part.
Prefabricated swimming pool
To Install a fioodlamp in prefabricated swimming pool make a circular hole wlth a diameter of 240 mm (Fig. 2).
Install the housing and one of the adhesive joints on the outer side of the pool. Instail the other adhesive joint on the inner side and
use two screws DIN 7981 4,8x16 to secure the three components. (Fig. 3). Ivlahe sure that the cable outlet of the housing remains
on the upper part.
To Install the clamp on the Inner side of the swimming pool, make sure that the heads of the screws DIN 7981 4,8x16, which have
been installed previousiy, coincide wlth the área reserved for them on the back part of the clamp.
Secure the clamp to the pool wall using 16 screws (Fig. 4)
4. ASSEMBLY:
After installation of the housing and the clamp, if it Is a prefabricated swimming pool, assemble the floodlamp.
To connect the floodlamp to the electric power supply Insert the cable through the gland seal nut (n. 24). Tíghten the gland seal nut
until you can verify that the cable wlil not yleid when you pulí on it wlth your hand.
Take the precautlon of leaving 1.5 m of cable wound on the floodlamp houusing in order to be able to remove the floodlamp to the
edge of the pool in the event that lamp replacement or handiing is required. (Fig. 5).
Insert the entire floodlamp assembly in the housing (Fig 6). In order to ofatain good pool lighting it ¡s important that the anagram of
the decorative ring (n. 2) is located on the upper part (Fig 7).
