ENGLISH
IMPORTANT: The instruction manual you are holding includes essential information on the safety measures to be
implemented for installation and start-up. Therefore, the installer as well as the user must read the instructions
before beginning installation and start-up.
Keep this manual for future reference.
To achieve optimum performance of the Mini light for swimming pool, follow the instructions provided below:
1. VERIFY THE CONTENTS OF THE PACKING:
The following accessories are included inside the box:
Concrete pool floodlamp
(33710 - 33686 - 36648 - 36643)
Housing body
Floodlamp unit
Bag of screws

2. GENERAL CHARACTERISTICS:

This floodlamp has been designed to be used fully submerged underwater in fresh water SPAS. It is a Class III electric
apparatus with very low safety voltage (12 V with alternating current).
The floodlamp complies with IPX8 degree of protection (resistance to penetration of dust, solid bodies and humidity)
at a nominal immersion depth of 2 m.
This floodlamp complies with international safety standards for lights, especially the EN 60598-2-18 standard: LIGHTS
PART 2: SPECIFIC REQUIREMENTS SECTION 18 LIGHTS FOR SWIMMING POOLS AND SIMILAR APPLICATIONS.
The manufacturer is not responsible in any circumstances for assembly, installation or start-up of any electric compo-
nents which have been inserted or handled at locations other than its own premises.
3. INSTALLATION:
• Never install in vertical position with the lamp facing downwards.
• In order to clearly light a pool it is recommended to install a 50 W floodlamp every 10 m
ming pools which are especially deep, a 50 W floodlamp is required for every 20 m
• In order to prevent glare, the floodlamps should be installed so that they face away from the residence or usual view
of the swimming pool. of water volume.
• In the event that lighting is used in training or competition pools, the floodlamps should be installed on the sides to
prevent glare on the swimmers.
• To avoid the need to empty the pool to change the lamp, we recommend that the floodlamp be installed in areas which
are accessible from the upper edge of the pool.
Prior to installation verify that the gland seal has been fully tightened.
The floodlamp should be placed on the wall of the pool at approximately 400-700 mm from the water surface (Fig. 1).
The crosshead and the clamp must be placed so that that the word "TOP" is located on the upper part The method
of fastening the crosshead mount to the pool wall varies depending on whether it is a floodlamp for concrete pools or
prefabricated pools.
Concrete swimming pool
To install a floodlamp in a concrete pool the housing (nº 13) should be fixed in the wall of the swimming pool (Fig.1).
Use eight 6x24 (nº 8) screws to secure the housing clamp to the pool.
Prefabricated swimming pool
To install a floodlamp in prefabricated swimming pool make a circular hole with a diameter of 110 mm (Fig. 2).
Install the housing (nº 13) and one of the joints (nº 14) on the outer side of the pool. Install the other joint on the inner
side and use two cylindrical screws (nº 14) to secure the three components (Fig. 3). Make sure that the cable outlet of
the housing remains on the upper part.
To install the housing clamp (nº 8) on the inner side of the swimming pool, make sure that the cylindrical heads of the
screws which have been installed previously coincide with the area reserved for them on the back part of the clamp
(Fig. 4). Use eight 6 x 24 screws (nº 821) to secure the clamp to the wall of the pool (Fig. 5). Make sure that the word
"TOP" is located on the upper part.
4. ASSEMBLY:
After the housing has been installed and the clamp inserted with the appropriate screws, then assemble the floodlamp.
Insert the cable in the cable duct (nº 2). Then, tighten the nut on the cable duct (nº 4). Take the precaution of leaving
1.5 m of cable wound on the body of the floodlamp (nº 3) in order to be able to remove the floodlamp to the edge of
the pool in the event that lamp replacement or handling is required (Fig. 6). Insert the entire floodlamp assembly in the
Prefabricated pool floodlamp
(33711 - 33687 - 36649 - 36644)
Housing body
Floodlamp unit
2 watertight joints
Bag of screws
