housing and secure it in the bayonet socket by turning to the right (Fig. 7). To completely ensure that the floodlamp is
firmly secured in the housing, install the lock screw (nº 8) which is supplied with the floodlamp kit (Fig. 8).
5. MAINTENANCE:
To remove the Floodlamp to the edge of the swimming pool (Fig. 9) detach the lock screw (nº 8) and remove the entire
floodlamp assembly by turning to the left with the spanner.
To remove the lamp unscrew the decorative cover on the floodlamp (nº 10), turn it around and use it as a spanner to
remove the ring from the floodlamp (nº 6) bayonet socket by turning to the left (Fig. 10). Remove carefully the lamp with
reflector and detach it from the lamp holder (nº 7), loosening the two screws which secure it (Fig. 11).
Then, continue in the opposite order of that described to assemble the Floodlamp, taking special care to perform the
following:
• Fully centre the butt joint in its housing.
• Firmly tighten all of the screws.
• Firmly tighten the gland seal nut.
Attention:
• Before any handling ensure that there is NO voltage supplied to the floodlamp.
• The new lamp should have the same characteristics as that supplied with the floodlamp, 50W 12 V halogen lamp with
non-blinding reflector and frontal lens.
• Never install lams without front lens.
• In order to ensure full
6. START-UP:
Ensure that the voltage the lamp receives is never greater than 12 V. The current must be supplied by an S.E.L.V.
transformer and protected by a correctly rated E.L.C.B.
The floodlamp should only operate underwater while secured to the vertical walls of the pool. Never switch on the
floodlamp if it is not underwater.

7. SAFETY WARNINGS:

• The persons who are in charge of assembly should have the required qualifications for this type of work.
• Avoid making contact with the electric voltage.
• Comply with the current standards regarding accident prevention.
• In this regard, the IEC 364-7-702 standards must be observed: WIRING IN BUILDINGS SPECIAL WIRING SWIM-
MING POOLS
• Any operation related to the maintenance or replacement of parts should be performed with the floodlamp disconnec-
ted from the electric power system.
• Do not handle with wet feet.
• The manufacturer is not responsible in any circumstances for assembly, installation or start-up of any electric compo-
nents which have been inserted or handled at locations other than its own premises.
• It is recommended not to use sealing filler in this product and in any case. only use products specifically designed to
work with ABS. Universal products should not be used.
