FOUNDATION
Article number: 331001
The foundation accessory is intended for installations that have no solid horizontal surface on which the stand can be
mounted. Note that the Foundation brackets are also required to mount the payment box on the foundation.
Package content:
P30
25. www.ecotap.nl
P18
Description
Stand
Stand cap
Plastic screw rivet
Hex bolt
Expansion shield anchor
Ring
Lock ring
Screw
Flange nut
Bolt bracket
Cap nut
Countersunk screw
Cable grommet
P19 P27
Size
1404 x 250 x 250 mm (hwd) 1
-
PH2
M12
M12
M12
M12
M5x16, T25
M12
-
M12
M12x35, hex8
-
P28
Quantity
1
4
4
4
8
4
4
4
1
4
4
1
