III. COMMON COMPONENTS
1. Backrest
2. Tire
3. Handrim
4. Wheel rim
5. Spokes
6. Rear Wheel Hub
7. Quick-release axle
8. Axle plate
9. Caster housing
10. Caster wheel
11. Caster leg
12. Footrest
13. Fork
14. Seat sling
15. Camber tube (not shown)
