Catalogue number Series
1
Bulletin 2198 Servo Drives
2198-H003-ERS
2198-H008-ERS
2198-H015-ERS
2198-H025-ERS
2198-H040-ERS
2198-H070-ERS
2198-H003-ERS2
2198-H008-ERS2
2198-H015-ERS2
2198-H025-ERS2
2198-H040-ERS2
2198-H070-ERS2
AC Line Filters
2198-DB08-F
2198-DB20-F
2198-DB42-F
Shunts
2097-R6
2097-R7
Capacitor Module
2198-CAPMOD-1300
1) Only the following motor and cable families are compatible with the Kinetix 5500 servo drives.
2) The following letters are used in the compatibility matrix to indicate model number description fields that do not
affect this DoC: x, y. These fields may be filled with any number(s) or letter(s).
3) If no series number is given, then all series are covered.
4) Legend as follows:
No = Product is not certified to this directive.
Yes = Product is certified to this directive.
N/R = this directive is not required for this product
Document Control Number: IMC-0040-D-EN
3
Description
Kinetix 5500, Frame 1, 195-528Vrms, 0.6 kW, Inverter
1.0Amp, Safe Torque-Off
Kinetix 5500, Frame 1, 195-528Vrms, 1.6 kW, Inverter
2.5Amp, Safe Torque-Off
Kinetix 5500, Frame 2, 195-528Vrms, 3.2 kW, Inverter
5.0Amp, Safe Torque-Off
Kinetix 5500, Frame 2, 195-528Vrms, 5.2 kW, Inverter
8.0Amp, Safe Torque-Off
Kinetix 5500, Frame 2, 195-528Vrms, 8.4 kW, Inverter
13.0Amp, Safe Torque-Off
Kinetix 5500, Frame 3, 195-528Vrms, 14.9 kW, Inverter
23.0Amp, Safe Torque-Off
Kinetix 5500, Frame 1, 195-528Vrms, 0.6 kW, Inverter
1.0Amp, Network Safe Torque-Off
Kinetix 5500, Frame 1, 195-528Vrms, 1.6 kW, Inverter
2.5Amp, Network Safe Torque-Off
Kinetix 5500, Frame 2, 195-528Vrms, 3.2 kW, Inverter
5.0Amp, Network Safe Torque-Off
Kinetix 5500, Frame 2, 195-528Vrms, 5.2 kW, Inverter
8.0Amp, Network Safe Torque-Off
Kinetix 5500, Frame 2, 195-528Vrms, 8.4 kW, Inverter
13.0Amp, Network Safe Torque-Off
Kinetix 5500, Frame 3, 195-528Vrms, 14.9 kW, Inverter
23.0Amp, Network Safe Torque-Off
460 Volt 7.5 Amp Three-Phase AC Line Filter
460 Volt 20 Amp Three-Phase AC Line Filter
460 Volt 42 Amp Three-Phase AC Line Filter
75 Ohm, 150W, External Shunt Resistor
150 Ohm, 80 W, External Shunt Resistor
Kinetix5500 Capacitor Module
Publication Rockwell Automation 2198-UM001D-FR-P – Mai 2014
Homologations CE
4
Directive
EMC LVD MD
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes N/R
Yes Yes N/R
Yes Yes N/R
Yes Yes N/R
Yes Yes N/R
Yes Yes N/R
2 / 3
