- Press the MENU button and the display will show:
showing the number of coffees by dose and by group.
Continuing to press the MENU button will show the number of coffees by selection.
NOTE
The individual counter for coffee dose type (1 espresso, 1 coffee, etc.) cannot be erased.

2.9.3.1.2. Technical menu display

Remember that to access the Technical MENU, the display must be in the OFF position (the display will show the word
OFF). If it is in the ON position (the display will show the name entered), in order to access the OFF mode, press the I/O
(ON/OFF) and, while pressing it, also press the TWO ESPRESSOS button on the left button pad immediately after
(based on the display used).
Once in OFF mode, in order to access the technical menu, you must press the the MENU button for around 10-15
seconds (based on the display used) and go into technical level programming mode.
- The first option which appears is:
Where you can select the language (English, French, German, Spanish, Italian) via the UP/DOWN
buttons. Once the desired language has been selected, press the MENU button and move on to the
following option:
The display will give you the option of showing the rest position of the machine, the TIME and the
TEMPERATURE on the top line of the display.
Using the UP/DOWN buttons, select "ENABLED" or "DISABLED" from this option.
- If "ENABLED" is selected, press the MENU button to move on to the following option:
On the display, Name 2 (the bottom line on the display) will appear, with the cursor situated in position
1 (of the 16 characters on the line). With the UP/DOWN buttons, select the letter or number required
(BLANK SPACE! " # $ % &...).
Pressing OK confirms the character and the cursor advances to the following character.
Continue this process until all the characters on the line are completed.
80
zzzzz GR:
xxxxxxxx
zzzzz:1 espresso, 1 coffee, etc.
GR: Group 1/2/3
xxxxxxx: Nº of coffees
Language
xxxxxxxx
Temperature/Hora Vis.
ENABLED/DISABLED
Name 2
xxxxxxx
INSTALLATION AND OPERATION MANUAL
