2.9. DISPLAY OPERATION (OPTIONAL)

2.9.1. New Iberital display

I
0
1
2.9.2. TFT display screen Iberital Expression Pro (touchscreen)

2.9.3. Display features

2.9.3.1. LCD display screen (non-touchscreen)

The display versions have two lines with 16 characters on each.
- OFF position:
- When the display is in the OFF position, it will show OFF and the time. In order to access the OFF
mode, press the I/O button.
- ON position:
- Press the I/O button and the display will show the boiler temperature in ºC, the time and the
name entered.
User MENU display: When the coffee machine switch is in position 2 and the display in the ON position (on the screen
the name entered will be shown), press the MENU for at least 5 seconds, and enter the user level programming mode.
INSTALLATION AND OPERATION MANUAL
MENU OK
2 3 4 5
100ºC
13:34
OFF hh:mm
xxxºC hh:mm
IBERITAL
1. ON/OFF
2. DOWN
3. UP
4. MENU
5. OK
77
